5 KVA 4000W 90V - 300V Heavy Duty Voltage Stabilizer for Mainline

Aulten brings to you an exclusive range of energy-efficient and automatic voltage stabilizers that are an ideal fit for all your appliances and their voltage needs.pliances and their voltage needs.

5 KVA 4000W 90V - 300V Heavy Duty Voltage Stabilizer for Mainline

Aulten brings to you an exclusive range of energy-efficient and automatic voltage stabilizers that are an ideal fit for all your appliances and their voltage needs.

Designed to take care of all the appliances in your home, Fans will start moving faster, lights will start glowing a little brighter, and everything else in between feels like a new energy in your home with the power you deserve. Recommended using in adversely affected areas where there are frequent drops in grid voltage and low connectivity. Aulten Mainline Stabilizer will also help your Inverter/UPS charge the batteries faster so you’re ready quicker, for any unforeseen power outages.

Product details

  • Item Dimensions LxWxH : 36 x 13 x 27 Centimeters.
  • Item Weight: 20 kg 200 g
  • Manufacturer: Aulten
  • Country of Origin: India
  • One-year replacement guarantee.

FEATURES

Technical Specifications

Working Range 90V - 300V
Output Voltage Range 200V-240V +/- 5% (190V Lowest & 252V Highest)
Low Voltage Cut Off 90V
High Voltage Cut Off 280V Cut Off (Recovery @ 300V)
Max. Output Current 20 Amps.
Initial Time Delay 5 to 10 seconds
Frequency 50 Hz. +/- 2 Hz.
Overload Protection via MCB (Stabilizer On/Off Mains)
By-Pass / Changeover via MCB (To be turned on 1 MCB at a time)
Operation Fully Automatic
Technology Relay Type
Display Type Digital (Multifunctional)
Display Parameters 'Lo' for Low voltage, 'Hi' for High Voltage
Voltage Display 'IP' for Input, 'OP' for Output
Idle Power Consumption Less than 10 watts*
Recommended MCB Use only 'C' Series MCB at your Distribution Box before connecting the stabilizer
